Conductive Ink
No. | Surface Resistance (Ω/sq) | Products name |
N-CH-A10 | 10Ω | Conductive Ink N-CH-A10 |
N-CH-A50 | 50Ω | Conductive Ink N-CH-A50 |
N-CH-AP50 | 50Ω | Conductive Ink N-CH-AP50 |
N-CH-P120 | 120Ω | Conductive Ink N-CH-P120 |
N-CH-A100 | 100Ω | Conductive Ink N-CH-A100 |
N-CH-AP100 | 100Ω | Conductive Ink N-CH-AP100 |
N-CH-P150 | 150Ω | Conductive Ink N-CH-P150 |
N-CH-A150 | 150Ω | Conductive Ink N-CH-A150 |
N-CH-AP150 | 150Ω | Conductive Ink N-CH-AP150 |
N-CH-P200 | 200Ω | Conductive Ink N-CH-P200 |
N-CH-A200 | 200Ω | Conductive Ink N-CH-A200 |
N-CH-AP200 | 200Ω | Conductive Ink N-CH-AP200 |
N-CH-POLED | PEDTO:PSS Inks Applied on OLED N-CH-POLED | |
N-CH-P10E3-10E6 | 10E3-10E6 | Water-based Surface Coating PEDOT:PSS compound Ink N-CH-P10E3-10E6 |
N-CH-P10E7 | 10E7 | Antistatic Ink N-CH-P10E7 |
N-CH-P10E4 | 10E4 | Antistatic Ink N-CH-P10E4 |
N-CH-P10E5 | 10E5 | Antistatic Ink N-CH-P10E5 |
N-CH-P10E3 | 10E3 | Antistatic Ink N-CH-P10E3 |
Application:
The flexible and high-transparent conductive film can be fabricated by Roll-to-Roll (R2R) micro-gravure printing, R2R slot-die printing, screen-printing or blade-coating via inks on PET. The conductive ink can also be used for the coating with anti-static or/and electromagnetic shielding. In addition, the films show excellent electro-conductibility, and can be applied for the electrodes of electroluminescent (EL) devices, liquid crystal display (LCD) and electrochromic display (EDC) devices. High-transparent conductive film can be matched in the fields of touch screen, touch panel, sensor, membrane switch, etc. Furthermore, flexible and high-transparent conductive film have some potential applications in flexible light-emitting device (LED), plastic LCD and solar cell.
Brand Name: | PEDOT | CAS No.: | 155090-83-8 |
---|---|---|---|
Purity: | 400s/cm | Chemical Formula: | Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate) |
Description of Product: | Aqueous dispersion, blue liquid. | Synonyms / Abbreviations: | PEDT / PSS, PEDOT: PSS |
